Vicor releases its first 20 Amp 24V Cool-Power ZVS step-down regulator
Vicor Cool-Power ZVS regulators deliver more power at higher temperatures than competing products without compromising power density or efficiency. Important attributes of Cool-PowerZVS regulator performance include zero-voltage switching topology, high silicon chip integration, and high-density LGA SiP packages. These high performance regulators are also simple to use, ensuring a one-time design success.
The Cool-Power ZVS step-down regulator PI3325-00-LGIZ is the largest current output ZVS step-down regulator available today for 24V/28V applications, providing regulated 5V output at voltages up to 20A. The PI3325-00-LGIZ is available in a 10x14x2.5mm LGASiP package to meet the growing demand for high power density in a growing number of applications. In addition, it provides pin-to-pin compatibility for the 48V input ZVS step-down regulator PI3325-00-LGI Billion, helping designs migrate quickly from 24VIN to 48VIN.
The PI3325-00-LGIZ requires only one output inductor and a minimum of passive components for a complete low-cost small design with a PCB substrate footprint of less than 740mm2. In addition, the parallel operation of the regulator can also increase the output current. The PI3325-00-LGIZ is one of the latest series of larger current 24VZVS step-down regulators released or soon to be released.
